TDTG series bucket elevator

clicks:121


  • Product features:

    ØStable and reliable operation and ease maintenance with a head pulley covered with rubber to increase friction and ensure steady running.

    ØThe specification of feeding interface can be determined by the customer's demand or the character of material.

    ØThanks to the processing technology of mechanical bending, riveting and welding, the main part is of good sealing quality.

    ØHigh-strength flap belt is of  large traction, steady running, good durability and reliability.

    ØUltrahigh molecular polythene bucket is used to convey material with low noise and long service life.

Major Technical Parameters:

  • Model

    TDTG26/13

    TDTG40/19

    TDTG50/23

    TDTG61/29

    TDTG61/33

    TDTG70/33

    TDTG70/38

    Capacity(t/h)

    10

    45

    60

    180

    350

    10

    45

    Power(kw)

    Power is determined by the height.

    Bucket gap (mm)

    140

    140

    140

    140

    250

    250

    250

    Belt speed(m/s)

    1.6-1.8

    1.6-2.0

    1.6-2.3

    1.6-2.3

    1.6-2.6

    1.6-2.6

    1.6-3.3

    Belt width(mm)

    150

    200

    250

    300

    350

    350

    400

    Maximum Height(m)

    45

    45

    45

    45

    45

    45

    45


　　　　　
